Specifications:
CPU and On Chip Memory :
- ESP32S3 series of SoCs embedded, Xtensa® dual-core 32-bit LX7 microprocessor, up to 240 MHz
- 384 KB ROM
- 512 KB SRAM
- 16 KB SRAM in RTC
- 8 MB PSRAM
WiFi :
- 802.11 b/g/n
- Bit rate: 802.11n up to 150 Mbps
- A-MPDU and A-MSDU aggregation
- 0.4 µs guard interval support
Bluetooth :
- Bluetooth LE: Bluetooth 5, Bluetooth mesh
- 2 Mbps PHY
- Long range mode
- Advertising extensions
- Multiple advertisement sets
- Channel selection algorithm #2
Peripherals:
GPIO, SPI, LCD interface, Camera interface, UART, I2C, I2S, remote control, pulse counter, LED PWM, USB 1.1 OTG, USB Serial/JTAG controller, MCPWM, SDIO host, GDMA, TWAI® controller (compatible with ISO 11898-1), ADC, touch sensor, temperature sensor, timers and watchdog
Integrated components on Module :
- 40 MHz crystal oscillator
- 16 MB SPI flash
PandaByte xS3 ESP32S3 Microcontroller Board Arduino Compatible
PRODUCT INFO
The PandaByte xS3 Microcontroller Board is a powerful and versatile development board built around the ESP32-S3-WROOM-01 SoC, making it one of the most advanced options in the ESP32 family. Equipped with 16 MB of flash memory, it offers ample space for code and data storage, while the inclusion of a massive 8 MB of PSRAM sets it apart from other ESP32 boards. This large PSRAM is particularly beneficial for applications that require intensive data processing, such as machine learning and complex IoT solutions, enabling efficient handling of larger models and datasets.
In addition to its Wi-Fi and Bluetooth capabilities, which provide robust wireless communication options, the board is ideal for real-time data processing and AI tasks on the edge. For quick experimentation and prototyping, the PandaByte xS3 includes a programmable single-color LED, an onboard push button, and an RGB LED, allowing users to test and validate their designs with ease.
Official ESP32-S3-WROOM-1 Datasheet
